AO523 1SAP250200R0001 ABB Analog Output Module
Manufacturer:
ABB
Product No.:
AO523
Condition:
In Stock
Product Type:
Analog Output Module
Product Origin:
SE
Weight:
127g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Features
| Feature | Details |
|---|---|
| 16 Analog Output Channels | Supports both voltage and current outputs. |
| High Resolution | 12-bit resolution including sign for accurate signal representation. |
| Galvanic Isolation | Provides protection against internal supply and other modules, enhancing system safety. |
| Configurability | Each output can be individually configured for different ranges: Voltage: -10 V to +10 V Current: 0 mA to 20 mA and 4 mA to 20 mA |
Technical Specifications
General Specifications
| Specification | Details |
|---|---|
| Weight | 0.127 kg |
| Dimensions | 67.5 mm (W) x 76 mm (H) x 62 mm (D) |
| Mounting Position | Horizontal or vertical (with derating at +40 °C) |
| Number of Channels | 16 (channels O0 ... O3 and O8 ... O11 for voltage/current; channels O4 ... O7 and O12 ... O15 for voltage only) |
Electrical Specifications
| Specification | Details |
|---|---|
| Power Supply | 24 V DC (-15 %, +20 %) |
| Current Consumption | From 24 V DC: Ca. 2 mA Normal Operation: 0.15 A + output loads Inrush Current: 0.040 A²s |
| Output Type | Bipolar for voltage Unipolar for current |
| Output Resistance | As current output: 0 Ω to 500 Ω As voltage output: Max. ± 10 mA |
| Output Loadability | Configurable per channel |
Environmental Specifications
| Specification | Details |
|---|---|
| Operating Temperature | 0 °C to +60 °C (horizontal) 0 °C to +40 °C (vertical, reduced output load) |
| Storage Temperature | -40 °C to +70 °C |
| Transport Temperature | -40 °C to +70 °C |
| Humidity | Max. 95 % (without condensation) |
| Air Pressure | Operating: > 800 hPa / < 2000 m Storage: > 660 hPa / < 3500 m |
Protection Features
| Specification | Details |
|---|---|
| Protection Against Reverse Voltage | Yes |
| Rated Protection Fuse | 10 A fast |
| Allowed Interruptions of Power Supply | DC Supply: Interruption < 10 ms, time between interruptions > 1 s AC Supply: Interruption < 0.5 periods, time between interruptions > 1 s |
