Analog Input Module | AAI143-H50/K4A00 Yokogawa
Manufacturer:
Yokogawa
Product No.:
AAI143-H50/K4A00
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
JP
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Yokogawa Model AAI143 Analog Input Module
| Model | AAI143-H50/K4A00 |
| Number of Input Channels | 16, isolated |
| Input Signal | 4 to 20 mA |
| Allowable Input Current | 24 mA |
| Withstanding Voltage | Between input and system: 1500 V AC, for 1 minute (*4) |
| Input Resistance |
Power ON: 270 Ω (20 mA) to 350 Ω (4 mA) (*2) Power OFF: 500 kΩ or larger |
| Accuracy | ±16 µA |
| Data Update Period | 10 ms |
| Transmitter Power Supply |
19.0 V or higher (at 20 mA) 25.5 V or less (at 0 mA) (output current limit: 25 mA) (*5) |
| Setting of 2-Wire or 4-Wire Transmitter | For each channel by setting pin |
| Drift Due to Ambient Temperature Change | ±16 µA/10 ˚C |
| Maximum Current Consumption | 230 mA (5 V DC), 540 mA (24 V DC) |
| Weight | 0.3 kg |
| External Communication | Pressure clamp terminal, MIL connector cable, dedicated cable (KS1) |
| HART Communication | Available (*3) |
Yokogawa Suffix & Option Codes
| Suffix Codes |
-H: With digital communication (HART protocol) 5: With no explosion protection 0: Basic type |
| Option Codes |
/K4A00: With KS Cable Interface Adapter (For connecting AEA4D Terminal Board) [Model: ATK4A-00] |
