ADV151-E10 | Yokogawa Digital Input Module
Manufacturer:
Yokogawa
Product No.:
ADV151-E10
Condition:
In Stock
Product Type:
Digital Input Module
Product Origin:
JP
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
ADV151 Digital Input Module Specifications
Yokogawa General Information
| Model | ADV151-E10 |
|---|---|
| Description | Digital Input Module (32-channel, 24 V DC, Isolated) |
Yokogawa Technical Specifications
| Item | Specifications |
|---|---|
| Number of Input Channels | 32 |
| Rated Input Voltage | 24 V DC (sink/source) |
| Input ON Voltage | 18 to 26.4 V DC |
| Input OFF Voltage | 5.0 V DC or less |
| Input Current (at Rated Input Voltage) | 4.1 mA ±20% / channel |
| Maximum Allowable Input Voltage | 30.0 V DC |
| Withstanding Voltage | Between input signal and system: 2 kV AC, for 1 minute Between commons: 500 V AC, for 1 minute, common every 16-channel (*3) |
| Functions |
|
| Input Response Time | 8 ms or less (for status input) |
| Minimum ON Detection Time | 20 ms (for pushbutton input) |
| Maximum ON/OFF Cycle | 25 Hz (for pushbutton input) |
| Maximum Current Consumption | 500 mA (5 V DC) |
| Weight | Approx. 0.30 kg |
| External Connection | Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
Yokogawa Suffix Codes
| Code | Description |
|---|---|
| -P | With pushbutton input |
| -E | With SOE capture (*1) |
| 5 | Without status display; with no explosion protection |
| 6 | With status display; with no explosion protection |
| E | Without status display; with explosion protection |
| F | With status display; with explosion protection |
| 0 | Basic type |
| 3 | With ISA Standard G3 option and temperature (-20 to 70 °C) option |
