CI865 Module Overview:

The CI865 module serves as the communication interface for Satt ControlNet within the AC 800M system. It facilitates the integration of older Satt I/O systems (including Rack I/O and Series 200 I/O) with the AC 800M controller platform. However, it is not suitable for use as a general ControlNet interface and is not compatible with High Integrity controllers.

Features and Benefits

Support for Satt 19 inch Rack I/O:

• Connects rack-based I/O systems to AC 800M using CI865 interface module.

Hot Swap Capability:

• Supports online replacement without requiring prior configuration.

I/O Handling:

• Manages I/O scanning for up to 31 distributed I/O systems.

General Information

• Article Number: 3BSE040795R1
• Communication Protocol: ABB's Satt I/O
• Master or Slave: Master
• Transmission Speed: Not specified
• Line Redundancy: No
• Module Redundancy: No
• Used with HI Controller: No

Detailed Data

• Max Units on CEX Bus: 4
• Connector: BNC
• 24 V Consumption (Typical): 120 mA
• Operating Temperature: +5 to +55 °C (+41 to +131 °F)
• Storage Temperature: -40 to +70 °C (-40 to +158 °F)
• Corrosion Protection: G3 compliant to ISA 71.04
• Protection Class: IP20 according to EN60529, IEC 529
• CE-Marking: Yes
• RoHS Compliance: DIRECTIVE/2011/65/EU (EN 50581:2012)
• WEEE Compliance: DIRECTIVE/2012/19/EU

Dimensions

• Width: 59 mm (2.3 in.)
• Height: 185 mm (7.3 in.)
• Depth: 127.5 mm (5.0 in.)
• Weight (Including Base): 700 g (1.5 lbs)
