ABB CI854BK01 PROFIBUS-DP/V1 Interface Module
Manufacturer:
ABB
Product No.:
CI854BK01
Condition:
In Stock
Product Type:
Interface Module
Product Origin:
SE
Weight:
700g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
General Info
| Parameter | Value |
|---|---|
| Article number | 3BSE069449R1 (CI854BK01) |
| Communication protocol | PROFIBUS DP-V1 |
| Master or slave | Master |
| Number of channels | 2 |
| Transmission speed | 9.6 - 12 000 kbit/s |
| Line redundancy | Yes |
| Module redundancy | Yes |
| Hot Swap | Yes |
| Used together with HI Controller | Yes |
| Max units on CEX bus | 12 |
| Connector | DB female (9-pin) |
| 24 V consumption typ. | 190 mA |
Environment and Certification
| Parameter | Value |
|---|---|
| Temperature, Operating | +5 to +55 °C (+41 to +131 °F) |
| Temperature, Storage | -40 to +70 °C (-40 to +158 °F) |
| Pollution degree | Degree 2 according to IEC/EN61131-2 |
| Corrosion protection | G3 compliant to ISA 71.04 |
| Protection class | IP20 according to EN60529, IEC 529 |
| CE- marking | Yes |
| Marine certificates | ABS, BV, DNV-GL, LR |
| RoHS compliance | DIRECTIVE/2011/65/EU (EN 50581:2012) |
| WEEE compliance | DIRECTIVE/2012/19/EU |
Dimensions
| Parameter | Value |
|---|---|
| Width | 59 mm (2.3 in.) |
| Height | 185 mm (7.3 in.) |
| Depth | 127.5 mm (5.0 in.) |
| Weight (including base) | 700 g (1.5 lbs) |
Kit Contents
| Item | Description |
|---|---|
| CI854B Communication Interface | |
| TP854 Baseplate | width: 60 mm |
