ABB CI840A 3BSE041882R1 Profibus DP-V1 Communication Interface

In stock
Manufacturer:
ABB
Product No.:
CI840A
Condition:
In Stock
Product Type:
Communication Interface Module
Product Origin:
Switzerland
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Overview

The CI840A Profibus DP-V1 Communication Interface by ABB (Article number 3BSE041882R1) is part of the S800 I/O system, a comprehensive, distributed, and modular process I/O system designed to communicate with parent controllers and PLCs over industry-standard field buses. The CI840A module is specifically designed for redundant applications and provides robust communication capabilities, ensuring reliability and efficiency in various industrial environments.

Key Features and Benefits

  • PROFIBUS DP-V1 Interface: Ensures seamless communication with controllers and PLCs.
  • Supervisory Functions: Provides supervision of I/O ModuleBus.
  • Isolated Power Supply: Delivers isolated power to I/O modules for enhanced safety and reliability.
  • OSP Handling: Manages Output Signal Processing (OSP) and configuration.
  • Input Power Fused: Protects the module from electrical faults.
  • Hot Configuration In Run (HCIR): Allows configuration changes without interrupting operations.
  • HART Pass-Through: Facilitates communication with HART devices.
  • Redundancy: Supports both line and module redundancy for increased reliability.
  • Hot Swap Capability: Enables modules to be replaced without shutting down the system.

General Information

  • Article Number: 3BSE041882R1
  • Communication Protocol: PROFIBUS DP-V1
  • Master/Slave Configuration: Slave
  • Line Redundancy: Yes
  • Module Redundancy: Yes
  • Hot Swap: Yes
  • Compatibility: Used together with HI Controller

Detailed Specifications

  • 24V Consumption: Typically 190 mA

Environmental and Certification

  • CE Marking: Yes
  • Electrical Safety Standards: EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201
  • Hazardous Location Certifications: C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2
  • Marine Certifications: ABS, BV, DNV-GL, LR
  • Operating Temperature: 0 to +55 °C (+32 to +131 °F), with approvals for +5 to +55 °C
  • Storage Temperature: -40 to +70 °C (-40 to +158 °F)
  • Pollution Degree: Degree 2, IEC 60664-1
  • Corrosion Protection: ISA-S71.04: G3
  • Relative Humidity: 5 to 95 %, non-condensing
  • Max Ambient Temperature: 55 °C (131 °F) for standard mounting, 40 °C (104 °F) for vertical mounting
  • Protection Class: IP20 according to EN60529, IEC 529

Dimensions

  • Width: 54 mm (2.13 in.)
  • Height: 119 mm (4.69 in.)
  • Depth: 96 mm (3.78 in.)
  • Weight: 0.2 kg (0.44 lbs.)
