ABB ACS880-01-02A4-3 Inverter Drive

ABB ACS880-01-02A4-3 Inverter Drive

Technical Specifications:

Manufacturer:
ABB
Product No.:
ACS880-01-02A4-3
Condition:
In Stock
Product Type:
Inverter
Product Origin:
Switzerland
Weight:
7000g
Shipping port:
Xiamen
Warranty:
12 months

ABB ACS880-01-02A4-3 Inverter Drive

General Information:

  • Global Commercial Alias: ACS880-01-02A4-3
  • Product ID: 3AUA0000107974
  • ABB Type Designation: ACS880-01-02A4-3
  • EAN: 6438177557326
  • Catalog Description: LV AC industrial wall-mounted single drive, IEC: Pn 0.75 kW, 2.4 A, 400 V
  • Long Description:
    • Customized for specific industries such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive.
    • Controls applications including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps, and fans.
    • Compact package for easy installation and commissioning.
    • Wall-mounted as standard, cabinet installation optional.
    • Enclosure classes up to IP55.
    • Built-in features: choke for harmonic filtering, brake chopper, EMC filter, communication protocol adapter, functional safety, external output filters, I/O extension modules.

Ordering Information:

  • Country of Origin: Switzerland（CH）
  • Customs Tariff Number: 85044085
  • HS Code: 850440
  • Invoice Description: ACS880-01-02A4-3 PN: 0.75 kW, IN: 2.4 A
  • Made To Order: Yes
  • Minimum Order Quantity: 1 piece
  • Order Multiple: 1 piece
  • Quote Only: No
  • Selling Unit of Measure: Piece

Dimensions:

  • Product Net Weight: 7.0 kg / 15.432 lb
  • Product Net Depth / Length: 226 mm / 8.898 in
  • Product Net Height: 409 mm
  • Product Net Width: 155 mm / 6.102 in
  • Package Level 1 Depth / Length: 574 mm
  • Package Level 1 Height: 281 mm
  • Package Level 1 Width: 256 mm
  • Package Level 1 Units: 1 carton

Technical Specifications:

    • Number of Phases: 3
    • Degree of Protection: IP21
    • Enclosure Type NEMA: Type 1
    • Altitude: 4000 m
    • Operating Humidity (RHamb): 5 ... 95%
    • Sound Level: 50 dB(A)
    • Multiple Battery Information: Lithium Coin, CR2032, 220 mAh, 3 V, 2 pcs, 6 g
    • Frequency (f): 47.5 ... 63 Hz
    • Frame Size: R1
    • Input Voltage (Uin): 380 ... 415 V
    • Mounting Type: Wall-mounted
    • Communication Protocols: CAN, DeviceNet, EtherNet/IP, MODBUS, Other Bus Systems, PROFIsafe, PROFIBUS, PROFINET IO
    • Number of Hardware Interfaces:
      • Industrial Ethernet: 0
      • Other: 4
      • Parallel: 0
      • PROFINET: 0
      • RS-232: 0
      • RS-422: 0
      • RS-485: 1
      • Serial TTY: 0
      • USB: 1
    • Includes: Control unit, PC connection
    • Analog Inputs: 2
    • Analog Outputs: 2
    • Number of Digital In/Outputs: 6 / 2
    • Output Currents:
      • Heavy-Duty Use (IHD): 1.8 A
      • Light-Overload Use (ILD): 2.3 A
      • Normal Use (In): 2.4 A
    • Output Powers:
      • Heavy-Duty Use (PHD): 0.55 kW
      • Light-Overload Use (PLD): 0.75 kW
      • Normal Use (Pn): 0.75 kW
    • Apparent Power Output: 1.7 kV·A
    • Efficiency Level: IE2
    • Standby Loss: 23 W

Complete Drive Module Efficiency (61800-9-2):

Operating Point Frequency / Current Absolute Loss Relative Loss Efficiency
0 / 25% 31 W 1.9% 73.8%
0 / 50% 33 W 2.0% 83.8%
0 / 100% 37 W 2.2% 89.5%
50 / 25% 32 W 1.9% 85.2%
50 / 50% 34 W 2.0% 91.2%
50 / 100% 39 W 2.3% 94.4%
90 / 50% 36 W 2.1% 94.7%
90 / 100% 43 W 2.6% 96.5%
Temperature Rating Maximum
Temperature 40 °C

Classifications:

  • ETIM 8: EC001857 - Frequency converter =< 1 kV
  • ETIM 9: EC001857 - Frequency converter =< 1 kV
  • UNSPSC: 39122001

Environmental Information:

  • SCIP: 41b0aacf-6aee-4855-80d0-b0b23674f3cc Finland (FI)
  • WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Additional Information:

  • Product Name: Frequency converter
