ABB ACS510-01-246A-4 Standard Inverter Driver

ABB ACS510-01-246A-4 Standard Inverter Driver

Technical Specifications:

Manufacturer:
ABB
Product No.:
ACS510-01-246A-4
Condition:
In Stock
Product Type:
Inverter
Product Origin:
Switzerland
Weight:
76000g
Shipping port:
Xiamen
Warranty:
12 months

ABB ACS510-01-246A-4 Standard Inverter Driver

Description: The ABB ACS510-01-246A-4 is a robust and efficient standard drive designed for industrial applications that require precise motor control. This drive enhances energy efficiency, reduces operational costs, and improves process performance across various settings.

Features:

  • Energy Efficiency: Advanced algorithms optimize energy consumption, significantly reducing costs.
  • Versatile Control: Offers scalar and vector control methods for diverse application needs.
  • Integrated EMC Filter: Complies with electromagnetic compatibility standards to minimize electrical noise.
  • User-Friendly Interface: Intuitive control panel simplifies setup, monitoring, and operation.
  • Safety Functions: Includes Safe Torque Off (STO) and other safety features to protect personnel and equipment.
  • Connectivity: Supports multiple communication protocols, ensuring easy integration into existing systems.
  • Durable Design: Built to withstand harsh industrial environments with a high protection rating.

Technical Specifications:

  • Input Voltage: 380-480 V AC
  • Output Power: 132 kW
  • Output Current: 246 A
  • Frequency Range: 0 to 500 Hz
  • Control Method: Vector control and scalar control
  • EMC Filter: Integrated
  • Overload Capacity: 150% for 1 minute
  • Protection Class: IP21 (standard)
  • Ambient Temperature: -10°C to +50°C (with derating above 40°C)
  • Cooling: Forced air cooling
  • Communication Options: Modbus RTU, Profibus, DeviceNet, CANopen, Ethernet

Ordering Information:

  • Country of Origin: Crafted in Switzerland (CH)
  • Customs Tariff Number: 85044099
  • Invoice Description: ACS510-01-246A-4,246A,380V,IP21
  • Made To Order: No
  • Minimum Order Quantity: 1 piece
  • Order Multiple: 1 piece
  • Quote Only: No
  • Selling Unit of Measure: Piece

Dimensions:

  • Product Net Weight: 76 kg
  • Product Net Dimensions (H x W x D): 420 mm x 350 mm x 955 mm
  • Package Level 1 Dimensions (H x W x D): 560 mm x 370 mm x 970 mm
  • Package Level 1 Units: 0 carton

Technical Details:

  • Number of Phases: 3
  • Degree of Protection: IP21
  • Enclosure Type NEMA: Type 1
  • Frequency (f): 47.5 ... 63 Hz
  • Frame Size: R6
  • Input Voltage (Uin): 380 … 480 V
  • Mounting Type: Wall-mounted
  • Output Current, Normal Use (In): 245 A
  • Output Power, Normal Use (Pn): 132 kW
  • Apparent Power Output: 170 kV·A
  • Efficiency Level: IE2
  • Standby Loss: 41 W
  • Complete Drive Module Efficiency (61800-9-2):

Operating Point Efficiency:

  • Frequency / Current:
    • 0 / 25 % - Absolute Loss: 715 W, Relative Loss: 0.4%, Efficiency: 92.8%
    • 0 / 50 % - Absolute Loss: 999 W, Relative Loss: 0.6%, Efficiency: 94.7%
    • 0 / 100 % - Absolute Loss: 1831 W, Relative Loss: 1.1%, Efficiency: 95.1%
    • 50 / 25 % - Absolute Loss: 808 W, Relative Loss: 0.5%, Efficiency: 96%
    • 50 / 50 % - Absolute Loss: 1201 W, Relative Loss: 0.7%, Efficiency: 96.9%
    • 50 / 100 % - Absolute Loss: 2324 W, Relative Loss: 1.4%, Efficiency: 96.9%
    • 90 / 50 % - Absolute Loss: 1541 W, Relative Loss: 0.9%, Efficiency: 97.7%
    • 90 / 100 % - Absolute Loss: 3132 W, Relative Loss: 1.8%, Efficiency: 97.7%

Environmental:

  • WEEE Category: Product Not in WEEE Scope

Classifications:

  • UNSPSC: 39122001

Additional Information:

  • Product Name: Frequency Converter

Applications: Ideal for use in pumps, fans, conveyors, mixers, compressors, and other machinery requiring precise speed and torque control, the ACS510-01-246A-4 ensures reliable and efficient operation, contributing to enhanced performance and energy savings in industrial processes.
