The AAI141-H00/K4A00 , manufactured by Yokogawa Electric Corporation, is an analog input module designed to convert analog signals into digital signals. It is used in various industrial applications such as process control, data acquisition, and test measurement.

Technical Specifications

• Input Type: Voltage or current
• Input Range: Configurable
• Measurement Accuracy: ±0.1% FS
• Resolution: 16-bit
• Sampling Rate: 1000 Hz
• Isolation: Input/output, power
• Communication Interface: RS-485

Suffix Codes Meaning

• H: Indicates the module is a high-density version with 16 input channels.
• 00: Indicates the basic configuration of the module with no additional options.

Option Codes

• /K4A00: With KS Cable Interface Adapter (Model: ATK4A-00)

Detailed Option Code Breakdown

• K: Confirms the module type as an analog input module.
• 4: Indicates the number of channels on the module. In this case, it has 4 channels for analog input.
• A: Signifies the type of analog input the module supports. Here, "A" means it accepts current input (typically 4-20mA).
• 00: Specifies any additional options on the module. "00" indicates there are no additional options included with this specific configuration.

This configuration ensures the AAI141-H00/K4A00 module is versatile and suitable for high-density, precise analog input applications with robust communication capabilities.
