Description

The Bently Nevada 991-01-XX-01-01 MOD:284318-01991 Thrust Transmitter is a sophisticated device designed for measuring axial thrust in rotating machinery. It converts the mechanical displacement measured by proximity probes into a proportional electrical signal, which can be used for monitoring and protection purposes. This transmitter is crucial for ensuring the safe and efficient operation of critical equipment by providing accurate thrust measurements.

Technical Specifications

• Input Voltage Range: 18-32 VDC
• Current Consumption: < 100 mA
• Operating Temperature Range: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: 95% non-condensing
• Signal Input: Compatible with Bently Nevada proximity probes
• Signal Output: 4-20 mA proportional to the measured thrust
• Output Load Resistance: 0-600 Ohms

Features

• High Accuracy: Provides precise measurements of axial thrust, crucial for machinery diagnostics.
• Robust Design: Engineered to withstand extreme environmental conditions, ensuring long-term reliability.
• Compatibility: Seamlessly integrates with various Bently Nevada monitoring systems and proximity probes.
• Ease of Use: Simple installation and configuration for quick deployment in industrial applications.

Weight and Dimensions

• Weight: 0.43 kg (0.9 lbm)
• Dimensions:
  • Height: 100.1mm  (3.94 inches)
  • Width: 73.9mm  (2.91 inches)
  • Depth: 53.3mm (2.1inches)
