Product Information
Product Number: 9200-01-50-01-04
Model: Two-Wire Velocity Seismoprobe Transducer
Manufacturer: Bently Nevada
Model Details
Model: 9200 - Two-Wire Seismoprobe Velocity Transducer
Mounting Angle/Minimum Operating: 01 - 0 ±2.5, 4.5 Hz (270 cpm) ⚙️
Connector Option: 05 - Terminal block top mount 🔌
Mounting Base Option: 01 - Circular; 1/4-20 UNC stud 🔩
Agency Approval Option: 04 - ATEX/IECEx 🛡️
Environmental Limits
Operating and Storage Temperature: -29°C to +121°C (-20°F to +250°F) 🌡
Humidity: To 95%, non-condensing 💧
Dynamic Operating Range: 2.54 mm (0.100 in) peak to peak 📶
Velocity Range: 25 mm/s (1 in/s) at 100 Hz ⚡
Electrical Properties
Coil Resistance: 1.25 kΩ ±5% ⚡
Locked Coil Inductance: 125 mH (typical) 🔧
Amplitude Linearity: ±5% from 0.01 to 5.0 in/s 📏
Weight: 300 grams (10.5 ounces) ⚖️
