900G04-0101 Honeywell Digital Input Module
Manufacturer:
Honeywell
Product No.:
900G04-0101
Condition:
In Stock
Product Type:
Digital Input Module
Product Origin:
USA
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Overview
The 900G04-0101 AC/DC Input Module offers sixteen individually isolated inputs powered externally. Each circuit has two terminals, and applying AC or DC power between these terminals activates the inputs. The module features a green LED state indicator for each channel to show when a digital input is ON.
Module Status Indicators
- Green Blinking Status LED: Indicates when the module is being scanned.
- Red Status LED: Indicates the presence of module diagnostics.
- Logic Control: Allows state inversion when necessary.
Connection Requirements
The module requires a Euro style 36-terminal terminal block.
Dimension
- 137mm H x 35.6mm W
5.4” H x 1.4” W
Weight
- 400g
Module Specifications
| Item | AC Application | DC Application |
|---|---|---|
| Inputs per Module | 16 | 16 |
| Input Voltage Range | 80 VAC to 264 VAC | 80 VDC to 125 VDC |
| Peak Voltage | 264 VAC | 150 VDC |
| AC Frequency | 47 Hz to 63 Hz | NA |
| Galvanic Isolation | Input to Input & Input to Chassis (350VAC max) | Input to Input & Input to Chassis (350VAC max) |
| On Voltage Level | 75 VAC | 75 VDC |
| Off Voltage Level | 20 VAC | 30 VDC |
| Input Impedance | 48 k ohms nominal | 48 k ohms nominal |
| Input Current | 1 mA nom. @120 VAC, 60 Hz<br>2 mA nom. @240 VAC, 50 Hz | 2 mA nom. @125 VDC |
| Minimum On Current | 0.3 mA | 0.3 mA |
| Maximum Off Current | 0.2 mA | 0.2 mA |
| Off to On Response Time | 6 ms + 1.5-line cycles max. | 6 ms + 2-line cycles max. |
| On to Off Response Time | 6 ms + 2-line cycles max. | 6 ms + 2-line cycles max. |
