8440-1800 Woodward EASYGEN-320 Module
Manufacturer:
Woodward
Product No.:
8440-1800
Condition:
In Stock
Product Type:
EASYGEN-320
Product Origin:
USA
Weight:
450g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🌐 Electrical Parameters
| Parameter | Value |
|---|---|
| 🔌 Voltage Range | • Rated Voltage: 277/480 Vac • Maximum Voltage: 346/600 Vac • Rated Voltage (Phase-Ground): 300 Vac • Surge Voltage Rating: 4.0 kV |
| ⚡ Frequency | • Mains Frequency: 40 Hz to 85 Hz • Generator Frequency: 15 Hz to 85 Hz |
| 📏 Accuracy | Class 1 accuracy for precise measurements. |
| 🖥️ Input Resistance | 2.0 MΩ |
| 💡 Power Consumption | Max power consumption per path: < 0.15 W |
| 🏎️ Speed Input | • Capacitive Isolated Speed Input: • Input Impedance: Minimum approx. 17 kΩ • Input Voltage: 875 mV (effective) |
| 🔋 D+ Input/Output | • Exciter Current: • 12 Vdc (Terminal 4): 0.11 A • 24 Vdc (Terminal 3): 0.11 A |
| 🔘 Discrete Inputs | • Input Range: 12/24 Vdc (6.5 to 32.0 Vdc) • Input Resistance: Approx. 6.7 kΩ |
🌡️ Environmental Specifications
| Parameter | Value |
|---|---|
| 🔊 Vibration Resistance | • Sinusoidal Vibration: 4G, 5 to 100 Hz • Endurance Vibration: 4G, 30 Hz, 1.5 hours • Random Vibration: 1.04 Grms, 10 to 500 Hz, 2 hours |
| 💥 Shock Resistance | • Shock: 40G peak, 11 ms |
📐 Dimensions
| Parameter | Value |
|---|---|
| 📏 Module Dimensions | 158 mm x 158 mm x 40 mm |
