Overview

The AI-TEK Passive Speed Sensor (Model: 70085-1010-416) is designed for reliable performance in demanding environments. It features a robust design and is optimized for various applications, providing essential feedback in speed detection systems. This sensor meets strict regulatory standards, making it suitable for hazardous locations.

Technical Specifications

• Brand: AI-TEK
• Model: 70085-1010-416
• Output Voltage (Standard): 60V (P-P)
• Output Voltage (Guarantee Point): 13.4V (P-P)
• DC Resistance: 210 ohms max
• Typical Inductance: 75 mH max
• Output Polarity: White lead positive
• Operating Temperature: -20 to +220°C
• Cable Length: 15 ft. (4.57 m)
• Net Weight: 16 oz. max
• Thread Size: 5/8-18
• Termination Type: Cable
• Agency Approval: FM listed Intrinsically Safe, Class I, Division 1, Groups A, B, C, D; ATEX Group II, Category 3G, Zone 2
• Temperature Rating: -20 to 220°C

FAQ

• What industries can use the AI-TEK Passive Speed Sensor?
  • The sensor finds applications across various industries, including oil and gas, chemical processing, and automotive.
• What is the maximum operating temperature of the sensor?
  • It operates efficiently within the temperature range of -20 to +220°C.
• Does the sensor have any safety approvals?
  • Yes, it is FM listed for Intrinsically Safe conditions and adheres to ATEX standards.
• What is the output voltage of the speed sensor?
  • The standard output voltage is 60V (P-P), with a guaranteed output of 13.4V (P-P).
