Overview

The AI-Tek 70085-1010-420 Passive Speed Sensor is engineered for high-performance speed monitoring in industrial environments. Designed with an FM listed intrinsically safe rating, it is suitable for hazardous areas and adheres to the highest safety standards, including Class I, Division 1 and ATEX Group II, Category 3G approval. This sensor delivers a 60V peak-to-peak output, ensuring accurate speed detection in critical applications.

Key Features:

• Brand: AI-Tek
• Model: 70085-1010-420
• Output Voltage:
  • Standard: 60V (P-P)
  • Guarantee Point: 13.4V (P-P)
• Output Polarity: White lead positive
• Operating Temperature Range: -20°C to +220°C
• Cable Length: 15 ft (4.57m)
• DC Resistance: 210 ohms max.
• Typical Inductance: 75 mH max.
• Thread Size: 5/8-18
• Termination: Cable
• Sensor Length: 7.25 in.
• Thread Length: 6 in.
• Net Weight: 16 oz max.

FAQ:

• 1. What is the output voltage of the AI-Tek 70085-1010-420 sensor?
  • The sensor provides a standard output voltage of 60V (P-P), with a guaranteed output of 13.4V (P-P).
• 2. Can the sensor operate in hazardous environments?
  • Yes, the AI-Tek Passive Speed Sensor is FM listed intrinsically safe and certified for ATEX Zone 2 environments.
• 3. What is the maximum operating temperature for this sensor?
  • The sensor can operate within a temperature range of -20°C to +220°C.
• 4. How long is the cable?
  • The sensor comes with a 15 ft (4.57m) cable.
• 5. What is the weight of the sensor?
  • The sensor has a maximum net weight of 16 oz.
