Overview:

The AI-TEK Speed Sensor (Model 70085-1010-413) is designed for high-performance applications requiring precise speed measurement. It is engineered to provide a reliable output voltage and operates within a wide temperature range, ensuring durability and accurate performance in various industrial environments. Ideal for use in machinery and equipment where speed feedback is critical, this sensor offers robust functionality and stability.

Key Features:

• Brand: AI-TEK
• Model: 70085-1010-413
• Output Voltage (Standard): 54 V (Peak-to-Peak)
• Guaranteed Output Voltage: 13.4 V (Peak-to-Peak)
• DC Resistance: 240 ohms (max.)
• Typical Inductance: 30 mH (reference)
• Output Polarity: White lead positive
• Operating Temperature: -65°C to +100°C
• Lead Length: 10 ft (3.05 m)
• Thread Length (A): 1.500 inches (38.10 mm)
• Housing Ground: Green/Yellow Tracer
• Net Weight: 14 oz (max.)
• Thread Length (A): 1.500 inches (38.10 mm)

FAQ:

1. What is the output voltage of this speed sensor?
   The standard output voltage is 54 V (Peak-to-Peak), with a guaranteed minimum of 13.4 V (Peak-to-Peak).

2. What is the operating temperature range of this sensor?
   This sensor operates within a temperature range of -65°C to +100°C, ensuring reliability under harsh conditions.

3. How long is the lead length?
   The lead length is 10 feet (3.05 meters), providing flexibility for installation.

4. What is the maximum DC resistance of the sensor?
   The maximum DC resistance is 240 ohms.

5. Where can this sensor be used?
   It is commonly used in machinery and equipment that require speed feedback, such as motors and industrial systems.
