Overview

The AI-TEK Speed Sensor (model 70085-1010-329) offers reliable performance in industrial applications, specifically engineered to provide high-quality speed feedback. It features an output voltage of 54V peak-to-peak (P-P) under standard conditions and is built to withstand extreme temperatures ranging from -65°C to +100°C. The sensor’s robust design makes it ideal for harsh environments, ensuring durability and consistent functionality.

Technical Specifications

• Brand: AI-TEK
• Model: 70085-1010-329
• Thread Length (A): 2.750 inches (69.85 mm)
• Output Voltage: 54V (P-P) (standard)
• Guaranteed Output Voltage: 13.4V (P-P)
• DC Resistance: Max 240 ohms
• Typical Inductance: 30 mH (reference)
• Output Polarity: White lead positive
• Operating Temperature: -65°C to +100°C
• Lead Length: 10 feet (3.05 meters)
• Housing Ground: Green/Yellow Tracer
• Net Weight: Max 14 oz. (397 g)

FAQs

• Q1: What is the output voltage of the AI-TEK Speed Sensor?
  A1: The standard output voltage is 54V peak-to-peak (P-P). The guaranteed output voltage is 13.4V (P-P).
• Q2: What is the temperature range for the AI-TEK Speed Sensor?
  A2: The sensor operates effectively between -65°C and +100°C.
• Q3: Can I use this speed sensor in harsh environments?
  A3: Yes, the AI-TEK Speed Sensor is designed to withstand extreme temperatures, making it ideal for harsh conditions.
