6ES7151-1BA02-0AB0 Siemens Interface Module
Manufacturer:
Siemens
Product No.:
6ES7151-1BA02-0AB0
Condition:
In Stock
Product Type:
Interface Module
Product Origin:
DE
Weight:
150g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
General Information
| Product Type Designation | IM 151-1 HF |
|---|---|
| Product Function | Isochronous mode: Yes |
Supply Voltage
| Mains Buffering | Mains/voltage failure stored energy time: 20 ms |
|---|
Input Current
| From Supply Voltage 1L+, Max. | 200 mA |
|---|
Power Loss
| Power Loss, Typ. | 3.3 W |
|---|
Address Area
| Addressing Volume | Inputs: 244 byte Outputs: 244 byte |
|---|
Interfaces
| Transmission Procedure | RS 485 |
|---|---|
| Transmission Rate, Max. | 12 Mbit/s |
PROFIBUS DP
| SYNC Capability | Yes |
|---|---|
| FREEZE Capability | Yes |
| Direct Data Exchange (Slave-to-Slave Communication) | Yes |
Protocols
| Supports Protocol for PROFINET IO | No |
|---|---|
| PROFIBUS DP | Yes |
| Protocols (Ethernet) | TCP/IP: No |
Interrupts/Diagnostics/Status Information
| Alarms | Yes |
|---|---|
| Diagnostics Function | Yes |
| Diagnostics Indication LED | Bus Fault BF (Red): Yes Group Error SF (Red): Yes Monitoring 24 V Voltage Supply ON (Green): Yes |
Potential Separation
| Between Backplane Bus and Electronics | No |
|---|---|
| Between Electronic Block and PROFIBUS DP | Yes |
| Between Supply Voltage and Electronics | No |
Isolation
| Isolation Tested With | 500 V DC |
|---|
Standards, Approvals, Certificates
| CE Mark | Yes |
|---|---|
| UL Approval | Yes |
Ambient Conditions
| Ambient Temperature During Operation | Min: 0 °C Max: 60 °C |
|---|
Dimensions
| Width | 45 mm |
|---|---|
| Height | 119.5 mm |
| Depth | 75 mm |
Weights
| Weight, Approx. | 150 g |
|---|
