5461-655 Woodward Final Driver Module
Manufacturer:
Woodward
Product No.:
5461-655
Condition:
In Stock
Product Type:
Final Driver Module
Product Origin:
USA
Weight:
1500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
- Power Supply: 24V DC (nominal), 18-30V DC range.
- Input Voltage: 24V DC.
- Current Consumption: 50 mA (typical).
-
Relays:
- R 01 (Relay 1): Load Share Self-Test indication (terminals 41/42).
- R 02 (Relay 2): Missing CAN Load Share Bus Member Alarm (terminals 43/46).
- R 03 (Relay 3): Load Share Monitoring Alarm (terminals 44/46).
- R 04 (Relay 4): GCB Feedback Monitoring Alarm (terminals 45/46).
- R 08 (Relay 8): Tie-Breaker Feedback Monitoring Alarm (terminals 53/54).
- Communication Protocol: CAN Bus for load sharing and status monitoring.
- Operating Temperature: -40°C to +85°C.
- Enclosure Type: Standard industrial housing, IP65 rated.
- Weight: Approximately 1.5 kg.
- Status Indicators: LEDs for GCB status, self-test, and alarms.
- Inputs: Discrete inputs for GCB conditions (DI 08, DI 11).
