Technical Specifications:
Product No.:
5SHX2645L0004
Product Type:
IGCT Module Board
ABB Model 5SHX2645L0004 IGCT Module Board
Technical Specifications
| Brand/Manufacturer |
ABB |
| Part Numbers |
5SHX2645L0004, 3BHL000389P0104, 3BHB003154R0101 |
| Dimensions |
35 cm x 29 cm x 6.5 cm |
| Weight |
2.56 kg |
| Country of Origin |
Sweden |
| Description |
IGCT Module Board |
Additional Technical Parameters
| Maximum Blocking Voltage |
4500 V |
| Continuous Forward Current |
2500 A |
| Gate Trigger Voltage |
4.5 V |
| Gate Trigger Current |
150 mA |
| Operating Junction Temperature Range |
-40°C to 125°C |
| Thermal Resistance, Junction to Case |
0.012 °C/W |
| Surge Current (10 ms) |
28 kA |
