396569-01-3 Emerson Non-isolated Analog I/O Module

In stock
Manufacturer:
Emerson
Product No.:
396569-01-3
Condition:
In Stock
Product Type:
Analog I/O Module
Product Origin:
USA
Weight:
350g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Technical Specifications

Parameter Specification
Analog Inputs (AIs)
  • 6 single-ended inputs
  • 4–20 mA or 1–5 Vdc
  • 12-bit resolution
  • 250 ohms (4–20 mA)
  • 1 MΩ (1–5 Vdc), ±0.1% full-scale accuracy
Analog Outputs (AOs)
  • 2 independently configurable outputs, 4–20 mA or 1–5 Vdc
  • 12-bit resolution, 0 to 750 ohms (4–20 mA)
  • minimum load 10k ohms (1–5 Vdc), ±0.2% full-scale accuracy
Power Supply Voltage 12–24 VDC
Power Consumption Maximum 3 W
Backplane Connector 36-pin gold-plated card-edge connector
Local Termination Two 10-point terminal block assemblies
Remote Termination Two 14-pin mass termination headers
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +85°C
Humidity 5% to 95% relative humidity, non-condensing
Module Size 6.0 x 4.0 x 1.5 inches (152 x 102 x 38 mm)
Weight 0.35 kg
Certifications CE, UL, Class I, Div. 2 hazardous locations
