Manufacturer Details

Manufacturer: Bently Nevada
Part No.: 330180-12-05
Product Type: 3300 XL Proximitor Sensor
Country of Origin: Made in U.S.A
Material: A308 aluminum
Connector Material: Gold-plated brass or gold-plated beryllium copper
System Length: 5 or 9 meters (including extension cable) or 1 meter (probe only)

Suffix Options

The part number 330180-12-05 refers to a specific configuration of the 3300 XL Proximitor Sensor. The -12 suffix indicates a total system length of 1.0 meter (3.3 feet) with no mounting hardware. The -05 suffix specifies that the sensor has ACSA, ATEX, and IECEx approvals.

Proximitor Sensor Temperature Range

Operating Temperature: -51°C to +100°C (-60°F to +212°F)
Storage Temperature: -51°C to +105°C (-60°F to +221°F)
Relative Humidity: Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68-2-3 for up to 56 days.

Dimensions and Weight

Dimensions (LWH): 81.3 mm * 61 mm * 63.5 mm (3.2" x 2.4" x 2.5")
Weight: 246 g (8.67 oz)
