2711P-T7C4D9 | Allen-Bradley | PanelView Plus Terminal
Manufacturer:
Allen-Bradley
Product No.:
2711P-T7C4D9
Condition:
In Stock
Product Type:
PanelView Plus Terminal
Product Origin:
USA
Weight:
1700g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Allen-Bradley 2711P-T7C4D9 PanelView Plus Terminal Technical Specifications
| Number of HW-interfaces industrial Ethernet | 1 |
| Number of HW-interfaces RS-232 | 1 |
| Number of HW-interfaces USB | 2 |
| Number of password levels | 2 |
| Number of function buttons, programmable | 22 |
| Number of online languages | 20 |
| Number of pixels, vertical | 480 |
| Power consumption | 70 W max (2.9 A at 24V DC), 39 W typical (1.6 A at 24V DC) |
| Touch technology | Resistive touch |
| Power input | DC |
| Built-in depth | 55 mm |
| Width of the front | 246 mm |
| Height of the front | 179 mm |
| Dimensions, approx | Touch: 179 x 246 x 55 mm |
| Cutout dimensions | Touch: 154 x 220 mm (6.08 x 8.67 inch) |
| Weight, approx | 1.7 kg |
| Degree of protection (NEMA), front side | 4X |
| Degree of protection (IP), front side | IP65 |
| Operating temperature | 0 °C |
| Heat dissipation | 240 BTU/hr |
| Shock | Operating: 15 G @ 11 ms, Nonoperating: 30 G @ 11 ms |
| Enclosure rating | NEMA Type 12, 13, 4X (Indoor use only), IP54, IP65 |
| Vibration | 10...57 Hz, 0.012 peak-to-peak displacement, 57...500 Hz, 2 G peak acceleration |
| Relative humidity | 5...95% noncondensing |
| Altitude, operating | 2000 m |
| Nonoperating temperature | -25 °C |
| Display area | 132 x 99 mm (5.2 x 3.9 inch) |
| Input Voltage | 18-30VDC |
| Input Power | 24 Volts DC |
| Touchscreen Lifespan | 1 million presses |
| Backlight | CCFL, 50,000 hours minimum at 25 °C (77 °F) |
| Battery Backup | CR2032 coin-cell lithium battery, 4-year life at 25°C (77°F) |
