22B-B012N104 | PowerFlex AC Drive Allen-Bradley

🔧 Manufacturer & Brand

Manufacturer: Rockwell Automation / Allen-Bradley

Brand: Allen-Bradley

Part Number / Catalog No.: 22B-B012N104

Product Line: PowerFlex 40

🔋 Electrical Specifications

Input Voltage: 240VAC

Input Phase: 3-Phase

Output Voltage: 0-230VAC

Output Power: 2.2 kW or 3.0 HP

Amperage: 12.0 A

Phase: 3 Phase

Control Method: Volts per Hertz (V/Hz), Sensorless Vector Control (SVC)

📡 I/O & Communication

Discrete Inputs: Four (4) Sink / Source

Discrete Outputs: One (1) N.O.; One (1) N.C. Contacts; Two (2) Digital / Optocoupler

Analog Input: Two (2) Unipolar 0-10VDC; 0-20mA; One (1) bipolar +/-10VDC

Analog Output: One (1) Analog Input 0-10VDC; 0-20mA

Communication: RS-485

Built-in Communication Port: RS485

⚙️ Installation & Enclosure

Installation: Panel Mount / DIN Rail

Zero Stacking: Supported

Enclosure Rating: IP20 / NEMA UL Type Open

Integrated Safety: Safe-Torque Off (STO) functionality

StepLogic Technology: Integrated

Filter: No CE Compliant Filter

📈 Additional Parameters

Weight: 3.5 lbs (1.6 kg)

Frequency Range: 0-400 Hz

Max Altitude: 1000 m without derating

Overload Capacity: 150% for 1 minute
