Bently Nevada Proximity Probe Housing Assembly (Model: 21000-28-05-30-095-04-02)

Description

Engineered for deep penetration applications, this assembly combines a 3" standoff with a 9.5" probe penetration. Features a CSA Type 4 certified aluminum housing and 304 stainless steel sleeve, fully compliant with API 670 Standard. Includes integrated 0.5m cable for compact installations in hazardous areas.

Technical Specifications

Brand: Bently Nevada

Part Number: 21000-28-05-30-095-04-02

Configuration Details:

• A: 28 = 8mm 3300 XL Probe (ATEX/IECEx/CSA certified)

• B: 05 = 0.5m (20") pre-terminated cable

• C: 30 = 3.0" Standoff Adapter

• D: 095 = 9.5" Penetration Depth (±0.5" adjustable)

• E: 04 = 3/4-14 NPT plug only

• F: 02 = 3/4-14 NPT thread

Critical Data:

• Total C+D Length: 12.5" (318mm) – Sleeve support mandatory

• Material: MIL-A-8625 aluminum with 304SS anti-corrosion sleeve

• Weight: 1.1kg (2.4lb) | Max Non-Label Depth: 13.5"

• Safety Certification: Class I Div 1 Groups A-D, Zone 0

• Temperature Range: -40°C to +150°C (short-term peak)

Package Contents

Includes reverse-mount probe, 3x PTFE-encapsulated O-rings, thread sealant, and explosion-proof certification documents. Shipped in ESD-protective packaging with 12-month warranty.
