Technical Specifications:
Manufacturer:
Bently Nevada
Product No.:
1900/27-01-00
Product Type:
Vibration monitor
Technical Specifications
| Category |
Specification |
| Compatible Transducers: |
Bently Nevada 200150 Accelerometer, Bently Nevada 190520 Accelerometer |
| Input Sensitivity: |
100 mV/g |
| Maximum Acceleration: |
20 g peak |
| Maximum Differential Input Voltage: |
4 volts peak to peak |
| AC/HDC Power Version: |
|
| AC Voltage: |
85 to 264 Vac |
| DC Voltage: |
110 to 370 Vdc |
| Current Draw: |
60 mA (typical), 120 mA (maximum) |
| Frequency: |
47 Hz to 440 Hz, or DC |
| Inrush Current: |
20 A (typical @ Vin=100 Vac), 40 A (typical @ Vin=200 Vac) |
| +24 Vdc Power Version: |
|
| Voltage: |
18 to 36 Vdc |
| Current Draw: |
300 mA (maximum) |
| Operating Temperature Range: |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature Range: |
-40°C to +85°C (-40°F to +185°F) |
| Humidity: |
0% to 95% non-condensing |
| Dimensions: |
132 mm x 132 mm x 71.1 mm (5.20 in x 5.20 in x 2.80 in) |
| Weight: |
400 g (0.85 lb) |
