1756-OF6VI Allen-Bradley ControlLogix Iso A/O Voltage Module
Manufacturer:
Allen-Bradley
Product No.:
1756-OF6VI
Condition:
In Stock
Product Type:
Iso A/O Voltage Module
Product Origin:
USA
Weight:
230g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Allen-Bradley 1756-OF6VI Module Specifications
Attribute | Value |
---|---|
Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1756-OF6VI |
Series | ControlLogix |
Module Type | Isolated Analog Output Module with voltage loop |
No. of Outputs | Six (6) individually isolated channels |
Outputs | 6-Point Isolated |
Output Signal | Voltage: +/-10VDC |
Backplane Current (5 Volts) | 250 milliamps |
Resolution | 14 bits across 21V (1.3 mV); 13 bits across 10.5V +sign bit |
Backplane Current (24 Volts) | 175 milliamps |
Accuracy | 0.5% of range |
Power Dissipation (Max) | 4.9 Watts at 60 Celsius |
Data Format | Integer mode (left justified, 2's complement) IEEE 32-bit floating point |
Removable Terminal Blocks | 1756-TBNH, 1756-TBSH |
Output Conversion Method | R-Ladder DAC, monotonicity with no missing codes |
Current Draw | 250 mA @ 5.1 VDC and 175 mA @ 24 VDC |
Open Circuit Detection Time | None |
Overvoltage Protection, Max | +/- 24 VDC |
Isolation Voltage | 50 Volts Continuous |
Operating Temperature Range | 0 °C to 60 °C (32 °F to 140 °F) |
Storage Temperature Range | -40 °C to 85 °C (-40 °F to 185 °F) |
Relative Humidity | 5% to 95% non-condensing |
Vibration | 2 g @ 10-500 Hz |
Shock | 30 g operational, 50 g non-operational |
