1756-L84E Allen Bradley ControlLogix5580 Controller

Technical Specifications

• Physical Dimensions:
  • Height: 145.2 mm
  • Width: 34.55 mm
  • Depth: 136.6 mm
• Weight: 0.394 kg
• Maximum Power Dissipation: 6.2 W
• Temperature Range:
  • Operating: 0°C to 60°C
  • Storage: -40°C to 85°C
• Relative Humidity: Maximum of 95% RH
• Vibration Rating: Tested up to 2 m/s² at a frequency of 500 Hz in accordance with IEC 60068-2-6.
• Shock Resistance: Can withstand shocks up to 30 g, compliant with IEC 60068-2-27.
• Maximum I/O Capacity:
  • Digital I/O: Supports up to 128,000 points.
  • Analog I/O: Handles up to 4,000 points.
  • Total I/O: A maximum of 128,000 points in total.
