170ADI35000 Schneider Discrete Input Module Modicon Momentum
Manufacturer:
Schneider
Product No.:
170ADI35000
Condition:
In Stock
Product Type:
Discrete Input Module
Product Origin:
USA
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
170ADI35000 Discrete Input Module Modicon Momentum - 32 Input 24 V DC
Main Specifications
- Range of Product: Modicon Momentum automation platform
- Product or Component Type: Discrete inputs base DC
- Group of Channels: 2 groups of 16 inputs
- Discrete Input Number: 32 (IEC 1131-2 Type 1)
- Discrete Input Voltage: 24 V DC
- Protective Treatment: TC
Technical Parameters
- Discrete Input Logic: Positive
- Input Voltage Limits: 24 V
- Voltage Range: -3 to 30 V
- Voltage State 0 (Guaranteed): -3 to 5 V
- Voltage State 1 (Guaranteed): 11 to 30 V
- Current State 0 (Guaranteed): ≤ 1.2 mA
- Current State 1 (Guaranteed): ≥ 2.5 mA
- Input Resistance: 4 kOhm
-
Response Time:
- 2.2 ms from state 0 to state 1
- 3.3 ms from state 1 to state 0
- Isolation Between Channels and Bus: 500 V AC
-
Power Dissipation:
- Maximum: 8.5 W
- Typical: 5.5 W
Environmental Specifications
- Marking: CE
- Local Signalling: 32 LEDs channel status
- Current Consumption: ≤ 250 mA at 24 V DC
- Dimensions: 47.5 mm x 141.5 mm x 125 mm
- Product Weight: 0.2 kg
