Technical Specifications:
Product Type:
Analog Input Module
🔧 Electrical Specifications
| 🌐 Parameter |
Details |
| 🔌 Input Impedance (4...20 mA) |
< 0.25 Ohm |
| 🔌 Input Impedance (±10 V) |
> 2200 kOhm |
| 🔌 Input Impedance (±5 V) |
> 2200 kOhm |
| 🌡 Temperature Drift (±10 V and ±5 V) |
30 %oFS/°C at 140 °F (60 °C) |
| 🌡 Temperature Drift (4...20 mA) |
60 %oFS/°C at 140 °F (60 °C) |
| ⏲️ Update Time |
25 ms |
| ⚡ Power Dissipation |
5.55 W |
| ⚡ Reverse Polarity Protection |
Internal |
| ⚡ Common Mode Voltage |
100 V DC between channels to ground |
| ⚡ Isolation |
1780 V AC for 1 minute (Channels to ground) |
| ⚙️ Absolute Accuracy (±10 V and ±5 V at 25 °C) |
±0.15% of full scale |
| ⚙️ Absolute Accuracy (4...20 mA at 25 °C) |
±0.25% of full scale |
| ⚙️ Absolute Accuracy (±10 V and ±5 V at 60 °C) |
±0.25% of full scale |
| ⚙️ Absolute Accuracy (4...20 mA at 60 °C) |
±0.45% of full scale |
📏 Physical Dimensions
| 📐 Dimension |
Measurement |
| 📏 Height |
4.9 in (125 mm) |
| 📏 Width |
5.6 in (141.5 mm) |
| 📏 Depth |
1.9 in (47.5 mm) |
| ⚖️ Net Weight |
0.474 lb (0.215 kg) |
🔍 Marking and Signalling
| 🛡️ Feature |
Details |
| 🔧 Marking |
CE |
| 💡 Local Signalling |
16 LEDs for channel status |
