Technical Specifications:
Manufacturer:
Allen-Bradley
Product No.:
1606-XLS960E
Product Type:
Power Supply Module
Features
- 3AC 380-480V Wide-range Input
- Three Input Fuses Included
- Width only 110mm, Weight only 1.5kg
- 95.3% Full Load and Excellent Partial Load Efficiencies
- 50% BonusPower, 1440W for up to 4s
- 110A Peak Current for 25ms for Easy Fuse Tripping
- Active PFC (Power Factor Correction)
- Active Filtering of Input Transients
- Negligible Low Input Inrush Current Surge
- Full Power Between -25°C and +60°C
- Current Sharing Feature for Parallel Use
- Internal Data Logging for Troubleshooting Included
- Remote Control of Output Voltage
- DC-OK Relay Contact
- Shut-down Input
Specification Quick Reference
| Output voltage |
DC 24V nominal |
| Adjustment range |
24 - 28V |
| Output current |
40 – 34.3A continuous
60 – 51.5A short term (4s) |
| Output power |
960W continuous
1440W short term (4s) |
| Output ripple |
< 100mVpp 20Hz to 20MHz |
| Input voltage |
3AC 380-480V -15%/+20% |
| Mains frequency |
50-60Hz ±6% |
| AC Input current |
1.65 / 1.35A at 3x400 / 480Vac |
| Power factor |
0.88 / 0.90 at 3x400 / 480Vac |
| AC Inrush current |
typ. 4.5A peak |
| Efficiency |
95.3 / 95.2% at 3x400 / 480Vac |
| Losses |
47.3 / 48.4W at 3x400 / 480Vac |
| Temperature range |
-25°C to +70°C operational |
| Derating |
24W/°C +60 to +70°C |
| Hold-up time |
typ. 25 / 25ms at 3x400 / 480Vac |
| Dimensions (WxHxD) |
110x124x127mm |
| Weight |
1500g / 3.3 lb |
