16 Circuit Discrete Input And Output GE IC660TBD022

Overview

The GE Fanuc IC660TBD022 is a powerful discrete input and output block designed for industrial automation systems. Offering 16 circuits for precise control and reliable operation, this block features high isolation capabilities, fast dropout time, and robust thermal management, making it a perfect choice for demanding environments.

Technical Specifications

• Brand: GE Fanuc
• Model: IC660TBD022
• Series: Genius I/O
• Part Number: IC660TBD022
• Description: 16 Circuit Discrete Input and Output Block
• Block Type: 16 input and output circuits
• Rated Voltage: 24 Volts DC
• Operating Voltage: 18 to 30 Volts DC
• Ripple: 10% maximum
• Power Supply Dropout Time: 10 milliseconds (DC)
• Heat Dissipation (Max): 68.8 Watts with 16 outputs on at 2 Amps
• Block to Block Isolation: 1500 Volts for 1 minute
• Dimensions (HxWxD): 224 x 88 x 100 mm (8.8 x 3.5 x 3.9 inches)
• Weight: 1.8 kg (4 pounds)
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 100°C (-40 to 212°F)

Applications

The IC660TBD022 is ideal for applications requiring discrete input and output control, including:

• Industrial Automation: Suitable for process control and manufacturing systems needing reliable digital I/O management.
• Data Acquisition: Used in systems that require accurate input and output signals for data processing and equipment control.
• Remote Monitoring: Ideal for remote systems where high reliability and fast recovery times are essential for system uptime.

FAQ

Q: What is the operating voltage range for the IC660TBD022?
A: The IC660TBD022 operates within a voltage range of 18 to 30 Volts DC, with a rated voltage of 24 Volts DC.

Q: How much heat dissipation does the IC660TBD022 have?
A: The device has a maximum heat dissipation of 68.8 Watts when all 16 outputs are on at 2 Amps.

Q: What is the block isolation rating for the IC660TBD022?
A: It provides 1500 Volts block-to-block isolation for 1 minute, ensuring system protection.

Q: What is the power supply dropout time?
A: The IC660TBD022 has a fast power supply dropout time of 10 milliseconds (DC).

Q: What are the operating and storage temperature ranges?
A: The device operates in temperatures from 0°C to 60°C (32°F to 140°F) and can be stored between -40°C and 100°C (-40°F to 212°F).
