140DAO85300 Schneider - Discrete Output Module
Manufacturer:
Schneider
Product No.:
140DAO85300
Condition:
In Stock
Product Type:
Discrete Output Module
Product Origin:
FR
Weight:
450g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🔧 Product Model and Type
| Product Model | 140DAO85300 |
| Product Range | Modicon Quantum automation platform |
| Product Type | AC discrete output modules |
| Discrete Output Number | 32 |
⚡ Electrical Specifications
| Supply Frequency | 47...63 Hz |
| Discrete Output Voltage | 20...253 V AC |
| Maximum Voltage Drop | 1.5 V |
| Absolute Maximum Output | 300 Vrms for 10 s AC, 400 Vrms 1 cycle AC |
🔋 Output and Load Specifications
| Maximum Load Current | 16 A rms per module, 4 A rms per group |
| Off-State Leakage Current | 0.88 mA 230 V per output |
| Surge Current | 2.5 A during 1 ms |
| Load Current per Output | 1 A rms 20...253 V |
🌡 Environmental and Protection Specifications
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Relative Humidity | 95% without condensation |
| Operating Altitude | ≤ 5000 m |
📏 Physical and Packaging Specifications
| Dimensions | Package: 4.7 cm (H) x 16.4 cm (W) x 31.5 cm (L) |
| Net Weight | 0.45 kg |
| Shipping Weight | 492 g |
| Number of Units in Package | 1 |
⚙️ Protection and Standards
| Protection Type | Internal output protection by 4 A fuse, RC filter |
| Product Certifications | cUL, FM Class 1 Division 2 |
| Standards | CSA C22.2 No 142, UL 508 |
| Marking | CE |
🔧 New Parameters
| Bus Current Requirement | 320 mA |
| Response Time | ≤ 0.5 ms (state 0 to state 1 and vice versa) |
| DV/dt | 400 V/ms |
| Power Dissipation | 1.60 + (1.0 V x total module load current) |
