140ACI03000 Schneider Analogue Input Module

Name: 140ACI03000 Schneider Analogue Input Module
Brand: Schneider
SKU: 140ACI03000
Price: 100.0 USD
Availability: InStock

Technical Specifications:

Manufacturer:

Schneider

Product No.:

140ACI03000

Condition:

In Stock

Product Type:

Analogue Input Module

Product Origin:

Weight:

300g

Shipping port:

Xiamen

Warranty:

12 months

Quantity

Range of Product:	Modicon Quantum automation platform
Product or Component Type:	Analogue input module
Type of Filter:	Single pole low pass - 3 dB at 15 Hz +/- 20 %

Analogue Input Number:	8
Input Type:	Differential
Addressing Requirement:	9 input words
Analogue Input Resolution:	12 bits
Linear Measuring Range:	1...5 V, 4...20 mA
Absolute Maximum Input:	50 V DC, 25 mA
Input Impedance:	250 Ohm current +/- 0.01 %, > 20 MOhm voltage
Absolute Accuracy Error:	+/- 0.05 % of full scale, +/- 0.1 % of full scale maximum
Linearity Error:	+/- 0.04 %
Accuracy Drift According to Temperature:	+/- 0.0025 % of full scale/°C, <= 0.005 % of full scale/°C
Common Mode Rejection:	> - 72 dB 60 Hz
Isolation Between Channels and Bus:	1000 V DC, 3000 V DC 60 s
Isolation Between Channels:	30 V DC
Update Time:	5 ms
Fault Type:	Broken wire 4...20 mA, Undervoltage range 1...5 V
Marking:	CE
Local Signalling:	For bus communication is present (Active) 1 LED (green) For external fault 1 LED (red) For channel is turned on 8 LEDs (green) For channel fault 8 LEDs (red)
Bus Current Requirement:	240 mA
Power Dissipation in W:	2 W
Module Format:	Standard
Net Weight:	0.7 lb(US) (0.3 kg)

Standards:	UL 508, CSA C22.2 No 142
Product Certifications:	FM Class 1 Division 2, cUL
Resistance to Electrostatic Discharge:	4 kV contact IEC 801-2, 8 kV on air IEC 801-2
Resistance to Electromagnetic Fields:	9.1 V/m (10 V/m) 80…1000 MHz IEC 801-3
Ambient Air Temperature for Operation:	32…140 °F (0…60 °C)
Ambient Air Temperature for Storage:	-40…185 °F (-40…85 °C)
Relative Humidity:	95 % without condensation
Operating Altitude:	<= 16404.2 ft (5000 m)
