135137-01 Bently Nevada 3500 Position I/O Module

Technical Specifications:

• Input Signals:
  • Proximitors: ±10 VDC, ±20 mA
  • RPTs (Resistive Position Transducers): ±10 VDC, ±20 mA
  • DC LVDTs (Linear Variable Differential Transformers): ±10 VDC
• Output Signals:
  • 4-20 mA
  • 0-10 VDC
• Accuracy: ±0.1% of full scale
• Linearity: ±0.1% of full scale
• Repeatability: ±0.05% of full scale
• Temperature Drift: ±0.01% of full scale per °C
• Power Supply: 24 VDC (±10%)
• Power Consumption: 2.5 W maximum
• Operating Temperature: -20 to 60°C (-4 to 140°F)
• Dimensions: 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in)
• Weight: 0.20 kg (0.44 lb)
