Features

• Power Supply: 24 VDC
• Memory: 7 K FLASH EPROM for program storage
• Inputs: 20 digital inputs, 24 VDC
• Outputs: 12 relay outputs, rated at 2A per channel
• Communication: Programmable RS 232 port, RS 485 system bus for network communication
• Real-Time Clock: Integrated real-time clock for time-sensitive operations
• High-Speed Counter: Capable of handling frequencies up to 10 kHz
• Advanced Functions: Includes PID control, extensive data handling capabilities, and other high-order functions

Technical Specifications

• Dimensions: 10.0" x 3.0" x 4.0" (25.4 cm x 7.6 cm x 10.2 cm)
• Weight: 1 lbs 10.1 oz (0.7 kg)
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% non-condensing
• Shock Resistance: 10 g for 11 ms
• Vibration Resistance: 2 g at 10 to 500 Hz

Electrical Specifications

• Input Voltage Range: 19.2 VDC to 28.8 VDC
• Power Consumption: 8 W max
• Relay Output Ratings: 2 A at 30 VDC or 250 VAC, resistive load
• Communication Speed: RS 232 up to 115.2 kbps, RS 485 up to 1 Mbps
