The PDC-MBMB-1 is a Mains Power Distribution Cable designed to transfer either 24Vdc or 48Vdc from one mains power rail (type MB-0001) to another mains power rail of the same type. It ensures reliable and efficient power distribution in industrial and commercial applications.
Technical Data
General
Type Number: FS-PDC-MBMB-1
Approvals: UL, CSA; FM pending
Cables
Type: HV8-55-c (AWG 8)
Length: 3 meters
Connectors
2-Pole Jackscrew:
Type Connector: D-TAB-200-JCK
Type Pin: D-TAB-200-8-S
Power Rating: 55 A
Temperature Rating: Max. 125°C (257°F)
Features
High Current Capacity: Capable of handling up to 55 A, suitable for heavy-duty applications.
Temperature Resistance: Designed to operate in environments with temperatures up to 125°C (257°F).
Robust Construction: Built with durable materials to ensure long-term reliability and safety.
Easy Connection: Equipped with 2-pole jackscrew connectors for secure and straightforward attachment to power rails.
