EPRO PR6423/10R-030 CON021 Eddy Current Displacement Sensor

EPRO PR6423/10R-030 CON021 Eddy Current Displacement Sensor

Ordering Information: PR6423/10R-030

The PR6423/10R-030 model features an 8mm tip diameter and 3/8”-24 UNF case threads. It is equipped with a reverse mount configuration and includes an 8.0-meter cable terminated with a Lemo connector. Notably, this model does not include an armored cable option.

Technical Specifications

Overview:

CON021 is an eddy current signal converter designed for critical turbine machinery applications such as steam, gas, and hydro turbines, compressors, pumps, and fans. It measures radial and axial displacement, position, eccentricity, and speed/keystrokes.

Features:

• High Accuracy Measurement: CON021 provides precise vibration measurements for monitoring shaft vibrations in rotating machinery, aiding in predicting equipment health and potential failures.
• Durability: Designed for industrial environments, capable of withstanding high temperatures, pressures, and harsh conditions to ensure long-term reliable operation.
• Multiple Control Algorithms: CON021 controller supports various algorithms including proportional control, integral control, derivative control, and PID control, suitable for different control requirements.
• Monitoring Multiple Variables: In addition to vibration, CON021 can also monitor process variables such as temperature, pressure, liquid level, and flow.
• Signal Conversion: As a signal converter, CON021 converts the sensor's raw signals into standard signals such as 4-20mA or digital signals for easier processing.
• Versatility: CON021 integrates multiple functions including signal amplification, filtering, and data communication, simplifying system integration and maintenance.

Specifications:

• Measurement Range:
  • Radial and Axial Displacement: ±5 mm
  • Position: ±25 mm
  • Eccentricity: 0% to 100%
  • Speed/Keystrokes: 0 to 10,000 RPM
• Accuracy:
  • Radial and Axial Displacement: ±0.5% full scale
  • Position: ±0.1% full scale
  • Eccentricity: ±1% full scale
  • Speed/Keystrokes: ±0.1% full scale
• Output Signals:
  • 4-20 mA
  • 0-10 V
  • ±10 V
• Power Supply:
  • 24 VDC
• Operating Temperature:
  • -40°C to 85°C
• Protection Rating: Designed for durability in industrial environments
