Key Features:

• 32 channel digital input module
• Input voltage range: 24 VDC
• Supports wet and dry contact inputs
• High-speed digital input with 8 ms scan time
• Configurable input filter and debounce time
• Integrated LED indicators for input status
• Compact DIN-rail mountable design
• Supports Yokogawa's CENTUM VP, ProSafe-RS, and other control systems

Technical Specifications:

• Number of input channels: 32
• Input voltage: 24 VDC
• Input signal type: Wet/Dry contact
• Input impedance: Approx. 4.7 kΩ
• Response time: 8 ms or less
• Insulation resistance: 100 MΩ or more
• Withstand voltage: 500 VAC for 1 minute
• Operating temperature: -10 to 60°C
• Maximum current consumption: 500 mA (5 V DC)
• Dimensions (W x H x D): 32.8 x 130 x 110 mm

Applications:

• Process control and automation systems
• Factory automation
• Monitoring and data acquisition
• Building management systems
• Power generation and distribution
