IMMFP12 Multi-function Processor Module Specifications

• Microprocessor: 32-bit, 16 MHz
• Memory: 512 kbytes ROM, 256 kbytes RAM, 347,712 bytes NVRAM
• Power: +5 VDC @ 2 A (10 W typical)
• Serial Ports: Two RS-232-C ports or one RS-485 and one RS-232-C port, up to 19.2 kbaud
• Station Support: 64 stations at 40-kbaud (IISAC01) or 8 stations at 5-kbaud (NDCS03 or NDIS01)
• Redundant Communication: 1 Mbaud serial link
• Programming: C, BASIC, BATCH, ladder logic, function codes, user-defined functions
• Dimensions: 35.56 mm W x 177.80 mm H x 298.45 mm L
• Weight: 0.27kg
• Mounting: Occupies one slot in INFI 90 OPEN module mounting unit
• Environment: 0° to 70°C, 5% to 95% humidity (noncondensing), noncorrosive air quality
• Certification: CSA certified for nonhazardous locations; Factory Mutual approved for hazardous locations
