1771-DXPS Allen-Bradley копроцесорен сериен разширителен модул
Manufacturer:
Allen-Bradley
Product No.:
1771-DXPS
Condition:
In Stock
Product Type:
Coprocessor Serial Expander Module
Product Origin:
USA
Weight:
900g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
📡 Communication Speed
| 🔄 Specification | 📊 Details |
|---|---|
| COMM1, COMM2, COMM3 | From 110 Kbps to 38.4 Kbps |
| Ethernet Speed | 10 Mbps |
🔧 Serial Standards
| 🔌 Specification | 📋 Details |
|---|---|
| Compatible Standards | RS-232C, RS-423, RS-485, RS-422A |
🔍 Error Detection
| 🚨 Specification | 📏 Details |
|---|---|
| Current | 500 mA at 30V AC/DC (resistive) |
🔒 Optical Isolation
| 💡 Specification | 📄 Details |
|---|---|
| Protection | Between communication ports and other circuitry |
🔌 Pin Configuration (Expander Module)
| 🔧 Specification | 🔑 Details |
|---|---|
| Main Module Keying | Pins 24 and 26 or 30 and 32 |
| Upper C Connector Keying | Pins 16 to 18 |
| Lower D Connector Keying | Pins 2 to 4 or 16 to 18 |
🔋 Power Supply
| 🔋 Specification | ⚡ Details |
|---|---|
| Power Source | 1771 chassis backplane |
⚠️ Installation Requirements
| 🔧 Specification | 📋 Details |
|---|---|
| ESD Prevention |
|
