KJ2201X1-BA1 Emerson - SIS Logic Solver

Product Information Sheet

• Model: KJ2201X1-BA1
• Type: SIS Logic Solver (SLS 1508)
• Manufacturer: Emerson
• Location: Round Rock, Texas
• Part Number: ATEX275
• Publish Date: July 2021

Specifications

• Power Requirements:
  • Local Bus Power: 24 VDC at 1 A
  • Maximum Current: 4 A
• Environmental Conditions:
  • Temperature Range: -40°C to +70°C
  • Shock Resistance: 10g ½ Sinewave for 11ms
  • Vibration Tolerance: 1mm Peak to Peak from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz
  • Airborne Contaminants: ISA-S71.04 –1985 Class G3
  • Relative Humidity: 5 to 95% Non-Condensing

Safety and Compliance

• Hazardous Atmosphere Ratings:
  • Certifications: II 3G Ex ec IIC Gc, CL. I Div. 2 GP. A, B, C, D, CL. I Zone 2 AEx/Ex ec IIC Gc
  • Approval Numbers: FM16ATEX0056U, FM21UKEX0017U, FM17US0286U, FM17CA0145U
