Emerson KJ3208X1-BA2 | DO 8-Channel 24 VDC Isolated

Technical Specifications for KJ3208X1-BA2

Brand: Emerson Automation Solutions

Model: KJ3208X1-BA2

Product Type: DO 8-Channel 24 VDC Isolated

Power Specifications:

• Local Bus Power: 12 VDC at 150 mA
• Field Circuit Power: 60 VDC at 1 A/Channel

Environmental Specifications:

• Temperature Range: -40°C to +70°C
• Shock: 10g ½ Sinewave for 11 msec
• Vibration: 1mm Peak to Peak from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz
• Airborne Contaminants: ISA-S71.04 – 1985 Class G3
• Relative Humidity: 5 to 95% Non-Condensing

Installation and Maintenance:

• Terminal Block Key Position: B5
• Maintenance: Non-serviceable by user, no calibration required
• Installation Note: Follow specific instructions for hazardous areas as per document 12P2046 and the DeltaV™ M-Series Hardware Installation and Reference manual.

Safety and Compliance:

• Classifications:
  • Class I Div. 2 Groups A, B, C, D
  • Class I Zone 2 AEx/Ex ec IIC Gc
